The Semi-Reflective coating processed by Boxin is not only durable but also has strong resistance to Laser Damage. It has a wide range of applications in Beam Splitting, Beam Sampling and Laser Output Coupling, and the Output Window of Laser Resonator.
Single wavelength semi reflective coating(UV)
| Angle of Incidence: 0º | Reflectance: R <90％±3％,R = 90％ - 95％±2％,R = 96％ - 98％±1％,R> 98％±0.5％ |
| Damage Threshold(355 nm): 3J /cm²，10ns pulse |
Single wavelength semi reflective coating(VIS/NIR)
| Angle of Incidence: 0º | Reflectance: R <90％±3％,R = 90％ - 95％±2％,R = 96％ - 98％±1％,R> 98％±0.5％ |
| Damage Threshold(1064 nm): 10J /cm²，10ns pulse |
Broadband semi reflective coating(VIS/NIR)
| Materials: According to customers’ request | Dimension Tolerance (mm): ±0.01 ～±0.2 |
| Bevel: 0.5mm, 45° | Scratch & Dig: 10/5～80/50 |
| Angle of Incidence: 0°，45° | Clear Aperture: >90% |
| PV: λ/20～λ/2 / Φ100 mm | Central Wavelength: 400nm-10.6μm |
| Coating: Multilayer dielectric coating of Electron beam alluviation |
Single wavelength semi reflective coating(UV)
Single wavelength semi reflective coating(VIS/NIR)
Broadband semi reflective coating(VIS/NIR)
